Overview

    1 Gigabit WAN port and 4 Gigabit LAN ports provide high-speed wired connectivity
    Supports IPsec/PPTP VPN protocols, Up to 20 IPsec VPN tunnels and 16 PPTP VPN tunnels are simultaneously supported
    SPI firewall and DoS defense protect your network from most known Internet attacks
    Professional 4KV lightning protection keeps your investment safe and sound

Features

    Dynamic/Static IP, PPPoE/Russian PPPoE, L2TP/Russian L2TP, PPTP/Russian PPTP and BigPond Cable WAN connection types
    Up to 20 IPsec VPN Tunnels, 16 PPTP VPN Tunnels
    DES, 3DES, AES128, AES192, AES256 Encryption
    MD5, SHA1 Authentication
    Manual, IKE Key Management Mode
    LAN-to-LAN IPsec VPN
    Static Routing
    MAC Clone, IP&MAC Binding, Bandwidth Control
    DHCP Client/Server, DHCP Address Reservation
    Virtual Server, Port Triggering, DMZ, UPnP
    SPI Firewall, PPTP/L2TP/IPsec Passthrough, FTP/TFTP/H.323/RTSP ALG
    DoS Attack Defence, Ping of Death
    ACL
    Dynamic DNS
    Remote Management

Specifications

HARDWARE FEATURES
Standards and Protocols     IEEE 802.3, 802.3u, 802.3ab
TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS, IPsec, PPTP
Interface     1 Gigabit WAN port
4 Gigabit LAN ports
Network Media     10BASE-T: UTP category 3, 4, 5 cable (Max 100m)
EIA/TIA-568 100Ω STP (Max 100m)
100BASE-TX: UTP category 5, 5e cable (Max 100m)
EIA/TIA-568 100Ω STP (Max 100m)
1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m)
Button     Reset Button
Power Supply     Internal Universal Power Supply
AC100-240V~ 50/60Hz Input
Dimensions (W X D X H)     8.23*4.96*1.02 in. (209*126*26 mm)
Flash     SPI 8MB
DRAM     DDR II 64MB
LED     PWR, SYS, WAN, LAN
PERFORMANCE
Concurrent Session     10000
NAT Throughput     120Mbps
IPsec VPN Throughput (3DES)     20Mbps
BASIC FUNCTIONS
DHCP     DHCP Server/Client
DHCP Address Reservation
MAC Clone     Modify WAN MAC Address
WAN Connection Type     Static/Dynamic IP,PPPoE/Russian PPPoE, PPTP/Russian PPTP, L2TP/Russian L2TP, Bigpond Cable
ADVANCED FUNCTIONS
ACL     IP/MAC/Domain Name Filtering
Advanced Routing     Static Routing
ARP Inspection     IP/MAC Binding
Bandwidth Control     IP/Port-based Bandwidth Control
Guarantee & Limited Bandwidth
Forwarding     Virtual Server
Port Triggering
DMZ
UPnP
Security     SPI Firewall
VPN Passthrough
FTP/TFTP/H.323/RTSP ALG
DoS Defence, Ping of Death
Local Management
VPN
PPTP VPN     16 PPTP VPN Tunnels
PPTP VPN Server
PPTP with MPPE Encryption
IPsec VPN     20 IPsec VPN Tunnels
LAN-to-LAN
Main, Aggressive Negotiation Mode
DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
MD5, SHA1 Authentication Algorithm
Manual, IKE Key Management Mode
Dead Peer Detection (DPD)
Perfect Forward Secrecy (PFS)
MANAGEMENT
Service     Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe)
Maintenance     Time Setting
Diagnostic
Firmware Upgrade
Factory Defaults/Reboot
Backup&Restore
System Log
Remote Management
Statistics
OTHERS
Certification     CE, FCC, RoHS
Package Contents     TL-R600VPN
Power Cord
RJ-45 Ethernet Cable
Quick Installation Guide
Resource CD
System Requirements     Microsoft® Windows® 8, 7,Vista™, XP or MAC® OS, NetWare®, UNIX® or Linux
Environment
Operating Temperature: 0℃~40℃ (32℉~104℉);
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
