Overview

    Shares your 4G LTE network with multiple Wi-Fi devices and enjoy download speeds of up to 150Mbps
    Powerful, integrated antennas provide stable wireless connections and better coverage
    Requires no configuration, just insert a SIM card and turn it on to enjoy a fast wireless connection
    Creates simultaneous dual band Wi-Fi networks, with maximum speeds of up to 300Mbps on the 2.4GHz band and 433Mbps on the 5GHz band
    Offers options and flexibility with the LAN/WAN port, allowing you to choose your connection type



Specifications

HARDWARE

Interfaces     3 10/100Mbps LAN Ports, 1 10/100Mbps LAN/WAN Port, 1 SIM Card Slot
Button     WPS/Reset Button, Wireless On/Off Button, Power On/Off Button
Dimensions (W X D X H)     7.95 x 5.55 x 1.32 in. (202 x 141 x 33.6 mm)
Antenna     3 Internal Wi-Fi Antennas,
2 Detachable External 4G LTE Antennas
External Power Supply     12V/1A
WIRELESS FEATURES
Wireless Standards     IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz
Frequency     2.4GHz and 5GHz
Signal Rate     300Mbps at 2.4GHz, 433Mbps at 5GHz
Reception Sensitivity     5GHz: 11a 54M: -74dBm
11ac HT20: -67dBm
11ac HT40: -64dBm
11ac HT80 : -60dBm
11n HT20: -71dBm
11n HT40: -70dBm

2.4G: 11g 54M: -76dBm
11n HT20: -73dBm
11n HT40: -67dBm
Transmit Power     CE: <20dBm(2.4GHz), <23dBm(5GHz)
Wireless Functions     Enable/Disable Wireless Radio, WDS Bridge, WMM,
Wireless Statistics
Wireless Security     64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions
Network Type     4G: FDD-LTE Cat4 (800/900/1800/2100/2600MHz)
TDD-LTE (2300/2600MHz)
3G: DC-HSPA+/HSPA+/HSPA/UMTS (900/2100MHz)
2G: EDGE/GPRS/GSM (850/900/1800/1900MHz)
SOFTWARE FEATURES
Quality of Service     Trafc Control(IP QoS)
Operating Modes     3G/4G Router, Wireless Router
WAN Type     Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)
Management     Access Control, Local Management, Remote Management
DHCP     Server, Client, DHCP Client List, Address Reservation
Port Forwarding     Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS     DynDns, NO-IP
VPN Pass-Through     PPTP, L2TP, IPSec
Access Control     Parental Control, Local Management Control, Host List,
Access Schedule, Rule Management
Firewall Security     DoS, SPI Firewall, IP Address Filter/Domain Filter,
IP and MAC Address Binding
Protocols     Supports IPv4 and IPv6
Guest Network     2.4GHz guest network x 1, 5GHz guest network x 1
OTHERS
Certification     CE, FCC, RoHS
Package Contents     AC750 Wireless Dual Band 4G LTE Router, Archer MR200
RJ45 Ethernet Cable
Power Adapter
Quick Installation Guide
Micro to Standard SIM Card Adapter
Nano to Standard SIM Card Adapter
System Requirements     Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, MAC OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 browers or higher,or other Java-enabled browsers
SIM Card
Environment     Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
