Overview


    Compatible with LTE/HSPA+/HSUPA/HSDPA/UMTS/EVDO USB modems, tested in the field
    3G/4G and WAN connection Backup guarantees an "Always-online" Internet connection
    Local wireless HD video sharing, with speeds up to 300Mbps
    Easy one-touch wireless security encryption with the WPS button
    Bandwidth control allows administrators to determine how much bandwidth is allotted to each PC

* 4G LTE Modems Compatibility apply to TL-MR3420

Specifications

HARDWARE FEATURES

Interface     1 USB 2.0 Port for LTE/HSPA+/HSUPA/HSDPA/UMTS/EVDO USB Modem
1 10/100Mbps WAN Port, 4 10/100Mbps LAN Ports, support the auto-Negotiation and auto-MDI/MDIX
Button     WPS/Reset Button
Wireless On/Off Switch
Power On/Off Button
External Power Supply     12VDC/1A
Dimensions ( W x D x H )     8*5.4*1.7 in. (204*138*44 mm)
Antenna Type     Omni directional, Detachable, Reverse SMA
Antenna Gain     2x5dBi
WIRELESS FEATURES
Wireless Standards     IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Frequency     2.4-2.4835GHz
Transmit Power     <20dBm
Wireless Security     Support 64/128 bit WEP, WPA-PSK/WPA2-PSK,
Wireless MAC Filtering
SOFTWARE FEATURES
Security     NAT Firewall, SPI Firewall, MAC / IP / Packet / Application / URL Filtering, Denial of Service(DoS), SYN Flooding, Ping of Death
Management     Web Based Configuration(HTTP), Web Based Firmware Upgrade
OTHERS
Certification     CE, FCC, RoHS
Package Contents     3G/4G Wireless N Router TL-MR3420
2 Antennas
Power supply unit
Ethernet Cable
Resource CD
Quick Installation Guide
System Requirements     Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ Windows 7 or Windows 8, MAC® OS, NetWare®, UNIX® or Linux.
Environment
Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
