Interface 4 *10/100Mbps LAN Ports
1 *10/100Mbps WAN Port
1 *USB 2.0 port
Power Supply 9V DC/0.8A
Button WPS/RST Button
LED Indicators 1 *Power, 1 *CPU, 1 *Wireless, 1 *WAN, 4 *LAN, 1 *USB
Antenna 3 *5dBi External Fixed Antennas
Environment Operating Temperature: 0C~55C
Storage Temperature: -20~65C
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing
WIRELESS FEATURES
Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
RF Frequency 2.4~2.4835GHz
Data Rate 802.11n: Up to 300Mbps
802.11g: Up to 54Mbps (dynamic)
802.11b: Up to11Mbps (dynamic)
Wireless Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)
Output Power < 20dBm (EIRP)
Channels 1-11 (North America), 1-13 (General Europe), 1-14 (Japan)
Modulation Type DBPSK, DQPSK, CCK and OFDM (BPSK,QPSK,16-QAM/ 64-QAM)
Reception Sensitivity 270M: -61 dBm@10% PER
135M: -65 dBm@10% PER
54M: -68 dBm@10% PER
11M: -85 dBm@8% PER
6M: -88 dBm@10% PER
1M: -90 dBm@8% PER
SOFTWARE FEATURES
Network WAN Setup: DHCP/Static IP/PPPoE/PPTP/L2TP
LAN Setup
ARP Binding Setup
Wireless Basic Settings
Multiple APs
Bridge Settings
MAC Authentication
WPS Settings
Advanced Settings
Quality of Service Bandwidth Control
Firewall IP/Port Filtering
MAC Filtering
URL Filtering
Denial of Service
Advanced Settings
NAT Port Forwarding
DMZ Settings
UPnP Settings
USB Storage Printer Server
FTP Server
Management Statistics
DDNS Settings
Time Zone Setting
Remote Management Setup
System Log
Upgrade Firmware
Save/Reload Settings
Administrator Setup
Schedule
