Features / filters
LAN standard     Fast Ethernet 10/100Mb/s
Maximum wireless transmission speed     300 Mb/s
Number of LAN ports     4x 10/100BaseTX (RJ45)
Number of WAN ports     1x 10/100BaseTX (RJ45)
Operating frequency     2.4 GHz
Wireless network standards     IEEE 802.11n, IEEE 802.11b, IEEE 802.11g, IEEE 802.11a,
Antenna gain     Under 10dbi
Antenna type     Outside
Application     Indoor
Built-in modem     None
Detachable antennas     No
Device type     Wireless router, Access point,
Management     By web browser
Type of case     Desktop
Type of device power supply     Power supply
WiFi encryption     WEP, WPA/WPA2,
Basic technical parameters
Interface
4 *10/100 Mbps LAN ports
1 *10/100 Mbps WAN port
Power supply     9V DC/0.5A
Antennas     2 *5dBi antennas
Buttons     1 *RST-WPS button, 1 *Power ON/OFF button
LED lights     1 *Power, 1 *CPU, 1 *Wireless, 1 *WAN, 4 *LAN
Dimensions (D x S x W)     5.8 x 3.0 x 1.0 in. (147.5 x 76 x 25 mm)
Wireless network features
Standards     IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Frequency     2.4~2.4835 GHz
Capacity     802.11n: up to 300 Mbps
802.11g: up to 54 Mbps
802.11b: up to 11 Mbps
EIRP     < 20dBm
Encryption     64/128bit WEP, WPA/WPA2, WPAPSK/WPA2PSK (TKIP/AES)
Sensitivity     270M: 61 dBm@10% PER
135M: 65 dBm@10% PER
54M: 68 dBm@10% PER
11M: 85 dBm@8% PER
6M: 88 dBm@10% PER
1M: 90 dBm@8% PER
Software features
Modes of operation     Wireless ISP Client Router
Wireless Client
Repeater (Range Extender)
Router
Bridge with AP
Client
Network     VLAN, IPv6
WAN types     DHCP/Static IP/PPPoE (dual access) /PPTP (dual access) /L2TP (dual access)
Wireless functions     Multiple SSIDs, MAC authentication, universal repeater, WDS, WPS
Schedule     Reboot schedule, Wi-Fi schedule
Firewall     MAC filtering, IP filtering, port filtering, URL filtering, port forwarding, DMZ
Management     Firmware update, QoS configuration, TR069, DDNS, access control
Package contents     Wireless router N300RT *1
Power supply *1
Mains cable *1
User's manual *1
Environment     Operating temperature: 0~40 degrees Celsius.
Storage temperature: 40~70 deg.
Humidity during operation: 10%~90% non-condensing
Moisture during storage: 5%~90% non-condensing
