1*Fiber Port, 4*10/100Mbps LAN Ports, 1*5dBi fixed antenna
1*Power ON/OFF button
VLAN, Repeater, WDS, Multi-SSID, QoS, WPS button

    Complies with IEEE 802.11n/g/b standards for 2.4GHz Wireless LAN.
    - Up to 150Mbps data rate for Wi-Fi network.
    - One fiber WAN port for fiber optical network connection.
    - Supports PPPoE, DHCP, Static IP, PPTP and L2TP broadband functions.
    - Provides 64/128-bit WEP, WPA, WPA2 and WPA/WPA2 (TKIP+AES) security.
    - Multiple APs function allows users to add more SSIDs accordingly.
    - The IP, MAC, Port and URL filtering makes access and time control more flexibly.
    - Supports VPN Pass-Through based on IPSec/PPTP/L2TP/IPv6.
    - Repeater function expands the wireless coverage and allows more terminals to access Internet.
    - VLAN function makes the network management more secure and efficient.
    - QoS function allocates network bandwidth reasonably.


HARDWARE FEATURES

Interface

• 4 *10/100Mbps LAN Ports
• 1 *10/100Mbps Fiber WAN Port

Power Supply

• 9V DC/0.8A

Button

• RST/WPS Button
• Power ON/OFF Button

LED Indicators

• 1 *Power, 1 *CPU, 1 *Wireless, 1 *WAN, 4 *LAN

Antenna

• 1 *5dBi Fixed Antenna

Dimensions (L x W x H)

• 6.0 x 3.7 x 0.9 In (152 x 94 x 24mm)

WIRELESS FEATURES

Standards

• IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

RF Frequency

• 2.4~2.4835GHz

Data Rate

• 802.11n: Up to 150Mbps
• 802.11g: Up to 54Mbps (dynamic)
• 802.11b: Up to11Mbps (dynamic)

EIRP

• < 20dBm

Wireless Security

• 64/128-bit WEP, WPA/WPA2 (AES/TKIP)

Reception Sensitivity

• 135M: -65 dBm@10% PER
• 54M: -68 dBm@10% PER
• 11M: -85 dBm@8% PER
• 6M: -88 dBm@10% PER
• 1M: -90 dBm@8% PER

SOFTWARE FEATURES

Operation Mode

• Wireless ISP Client Router
• Wireless Client
• Repeater(Range Extender)
• Router, Bridge with AP, Client
• WAN Type
• DHCP/Static IP/PPPoE(Dual access)/PPTP(Dual access) /L2TP(Dual access)
• IPv6 Network
• WAN Setting, LAN Setting, RADVD for IPv6, IPv6 Tunnel to IPv4

Wireless Functions

• Multiple SSID, MAC Authentication, Universal Repeater, WDS,
• WPS, IPTV

Schedule

• Reboot Schedule, Wireless Schedule

Firewall

• SPI Firewall, MAC Filtering, IP Filtering, Port Filtering,
• URL Filtering, Port Forwarding, DMZ, NAT Mapping

Management

• QoS, TR-069 config, DDNS, SNMP, DoS, Notice Setting,
• Access Control, Refresh Buffer Memory etc.
• Others

Package Contents

• F1 Wireless Router *1
• Power Adapter *1
• Ethernet Cable *1
• Quick Installation Guide *1

Environment

• Operating Temperature: 0~40 Celsius
• Storage Temperature: -40~70 Celsius
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing
