Standards

IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

Signal Rate

Up to 300Mbps

Frequency Range

2.4-2.4835GHz

Transmit Power

20dBm(MAX)

Data Transfer Rate

802.11n:
40MHz(300Mbps, 270Mbps, 240Mbps, 180Mbps, 120Mbps, 90Mbps, 60Mbps, 30Mbps)
20MHz (144Mbps, 130Mbps, 115Mbps, 86Mbps, 57Mbps, 43Mbps, 28Mbps, 14Mbps) (Auto-Sense)
801.11g:
(54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps)
802.11b:
(11Mbps,9Mbps, 6Mbps, 5.5Mbps, 2Mbps, 1Mbps)

Wireless Mode

AP, WDS, AP+WDS, Repeater, Client, Multiple AP

Wireless Security

64/128-bit WEP,
WPA-PSK/WPA2-PSK (TKIP/AES)
SSID Broadcast Enable/Disable
Wireless MAC Filtering

Hardware

Standards

IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX

Interface

1 * 10/100M Auto MDI/MDIX RJ45 WAN port
4 * 10/100M Auto MDI/MDIX RJ45 LAN port

LED

PWR,WPS, WAN, 1X-4X

Button

Default, WPS

Antenna

2 * internal 4dBi antennas

Power Supply

DC 9V/500mA(Output)

Dimensions (L xW x H )

49 x 88 x 115 mm

Weight

112 g

Software

WAN Type

DHCP(Dynamic IP), PPPoE, Static IP, WISP

Port Forwarding

Virtual Servers, Port Triggering, UPnP, DMZ, FTP Private Port

QoS

WMM, Bandwidth Control

Access Control

IP/MAC/Domain filtering

VPN Pass-through

PPTP, L2TP, IPSEC

Others

DDNS, Static Routing, WOL, Remote Management, Firmware upgrade

Others

Certification

FCC, CE

Environment

Operating Temperature: 0℃~40℃
Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Package

1 * WF2420
1 * Quick Installation Guide
1 * Power Adapter
1 * Ethernet Cable
