16-Port 10/100Mbps Unmanaged Switch

16*10/100Mbps auto-negotiation RJ45 Ports
Metal case with rack-mounted (19inch)

    Complies with IEEE 802.3, IEEE 802.3u and IEEE 802.3x standards.
    - Provides 16 10/100Mbps auto-negotiation ports.
    - Supports IEEE 802.3x flow control for full duplex mode and backpressure for half-duplex mode.
    - Supports MAC address auto-learning and auto-aging.
    - LED indicators for monitoring power, link and activity.
    - Plastic case, desktop or wall-mounting design.
    - External power supply.

HARDWARE FEATURES

Standards

• IEEE 802.3,
• IEEE 802.3u
• IEEE 802.3x

Interface

• 16*10/100Mbps auto-negotiation RJ-45 Ports (Auto MDI/MDIX)

Power Supply

• 3.3V DC/2A

Dimensions

• 440mm x 160.2mm x 44.6mm (L x W x H)

LED

• Power, Link/Activity

MAC Address Learning

• Auto-learning, auto update

MAC Address Table

• 8K

Network Media

• 10Base-T: UTP Cat 3, 4, 5 cable (100m, max.)
• EIA/TIA-568 100Ω STP (100m max.)
• 100Base-Tx: UTP Cat 5, 5e cable (100m, max.)
• EIA/TIA-568 1100Ω STP (100m max.)

Backup Bandwidth

• 3.2Gbps

Transmission Method

• Store-and-forward

Environment

• Operating Temperature: 0~40 Celsius
• Storage Temperature: -40~70 Celsius
