TOTOLINK GS1000 PG05 1-Port Gigabit GPON Terminal

•     Complies with ITU-T G.984.1, ITU-T G.984.2, ITU-T G.984.3 and ITU-T G.984.4
•     1*gigabit port, 1*SC/UPC optical interface
•     Downstream rate up to 2.488Gbps and upstream rate up to 1.25Gbps.
•     Supports OMCI (ONT Management Control Interface) remote management.
•     Supports remote diagnosis to accurate locate error

HARDWARE FEATURES

Interface

• 1 *1000Mbps LAN port
• 1 *SC/UPC GPON port

Power Supply

• 9V DC / 0.5A

Button

• 1 *RST Button
• 1 *Power ON/OFF Button

LED Indicators

• 1 *Power
• 1 *GPON
• 1 *LAN
• 1 *LOS

Data Rate

• Upstream: 1.25Gbps
• Downstream: 2.5Gbps

Standard

•  IUT G.984.1,
• G.984.2,
• G.984.3,
• G.984.4
• IEEE 802.3,
• IEEE 802.3u

Optical Module

• Class B+

Distance

• Up to 20Km

WIRELESS FEATURES

VLAN

• 802.1Q tag VLAN
• Authentication based on SN and Password
• VLAN Auto Detect

Security

• AES Encryption
• Packet Filter based on VLAN

Management

• Managed by Web
• OMCI and Telnet
• Specified the management IP
• Reset to Factory default
• Real-time statistics
• Optical Diagnostic

Package Contents

• GS1000 GPON Terminal*1
• Power Adapter *1
• Ethernet Cable *1
• Quick Installation Guide *1

Environment

• Operating Temperature: 0~40 Celsius
• Storage Temperature: -40~70 Celsius
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing
