12dBi omni-directional operation highly enlarges the wireless coverage
    N female connector, compatible with most of the wireless equipments
    Weather proof design, suitable for all weather condition
    Provided mounting kits enable easy installation for various environments

ANTENNA
Weight     0.5kg
Frequency     2.4GHz~2.5GHz
Impedance     50 Ohms
Gain     12 dBi
Radiation     Omni-directional
VSWR(MAX.)     < 2.0
HPOL Beamwidth     360°
VPOL Beamwidth     12°
Polarization     Linear, Vertical
Connector Type     N Female
Mounting     Pole Mount / Wall Mount
Application     Outdoor
Lightning Protection     DC Ground
Operating Temp.     -40℃~65℃(-40℉~149℉)
Storage Temp.     -40℃~80℃ (-40℉~176℉)
Operating Humidity     10%~90% non-condensing
Storage Humidity     5%~90% non-condensing
Safety, Emission and Others     CE, FCC, Compliant with RoHS
Package Contents     12dBi Outdoor Omni-directional Antenna
Installation mounting kits
User Guide
Dimension     1200mm
