Expand Wi-Fi Network for Ultimate Performance
    Expanded 450Mbps on 2.4GHz + 1300Mbps on 5GHz totals 1750Mbps Wi-Fi speeds
    Three adjustable external antennas provide optimal Wi-Fi coverage and reliable connections
    Gigabit Ethernet port acts as a wireless adapter to connect a wired device to your network at gigabit speed
    Intelligent signal light helps to find the best location for optimal Wi-Fi coverage by showing the signal strength
    Works with any Wi-Fi router or wireless access point

HARDWARE FEATURES
Plug Type     EU, UK, US
Standards and Protocols     IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Interface     1 * 10/100/1000M Ethernet Port (RJ45)
Button     RE (Range Extender) Button, Reset Button, LED Button, Power Button
Dimensions (W X D X H)     6.4x 3.0 x 2.6 in. (163 x 76.4 x 66.5mm)
Power Consumption     9W（max power consumption）
Antenna     3* external
WIRELESS FEATURES
Frequency     2.4GHz & 5GHz(11ac)
Signal Rate     5GHz:Up to 1300Mbps
2.4GHz:Up to 450Mpbs
Reception Sensitivity     5GHz：
11a 6Mbps:-93dBm@10% PER
11a 54Mbps: -76dBm@10% PER
11ac HT20 mcs8: -68dBm@10% PER
11ac HT40 mcs9: -64dBm@10% PER
11ac HT80 mcs9: -61dBm@10% PER
2.4GHz
11g 54M: -77dBm@10% PER
11n HT20 mcs7: -73dBm@10% PER
11n HT40 mcs7: -70dBm@10% PER
Wireless Modes     Range Extender
Wireless Functions     Wireless Statistic
Concurrent Mode boost both 2.4G/5G WiFi band
High Speed Mode for great speed for HD Gaming and video
Access Control
LED Control
Domain Login Function
Wireless Security     64/128-bit WEP
WPA-PSK / WPA2-PSK
Transmission Power     <20dBm(2.4GHz)
<23dBm(5GHz)
OTHERS
Certification     CE, FCC, RoHS
