Standards
|
IEEE 802.11n,IEEE 802.11g, IEEE 802.11b |
|
| Ports |
Gigabit Ethernet (RJ-45) Port *1(Support IEEE802.3af PoE), Console Port *1 |
| Operating modes |
Cluster, Standalone Mode |
| Frequency range | 2400 MHz ÷ 2483,5 MHz |
| Signal Rate |
11n- up to 300Mb/s (dynamic), 11g- up to 54Mb/s (dynamic), 11b- up to 11Mb/s (dynamic) |
| Reception Sensitivity |
300M -71dBm, 150M -75dBm, 54M -78dBm, 11M -93dBm, 6M -92dBm, 1M -96dBm |
| Wireless Functions |
Multiple SSIDs (Up to 8 SSIDs), Enable/Disable Wireless Radio, Automatic Channel Assignment, Transmit Power Control (Adjust Transmit Power on dBm), QoS(WMM), Load Balance, Wireless Schedule, Wireless Statistics based on SSID/AP/Client |
| Wireless Security |
Captive Portal Authentication, Wireless Mac Address Filtering, Wireless Isolation Between Clients, SSID to VLAN Mapping, Rogue AP Detection, 802.1X Support, 64/128/152-bit WEP / WPA / WPA2-Enterprise,WPA-PSK / WPA2-PSK |
| CLI (Command Line Interface) | Yes |
| Cluster | Up to 24 APs in one cluster |
| EAP Controller Software | Yes |
| Email Alerts | Yes |
| LED ON/OFF Control | Yes |
| Management MAC Access Control | Yes |
| SNMP | v1,v2c |
| System Logging Local/Remote Syslog | Local/Remote Syslog |
| Telnet | Yes |
| Web-based Management | HTTP/HTTPS |
| Antenna | Internal 2* 4dBi Omni |
| Dimensions | 7.1 x 7.1 x 1.9 in. (180*180*47.5mm) |
| Power | PoE or External 12VDC / 1A Power Supply |
| Mounting | Ceiling /Wall Mounting (Kits included) |
| Physical Security Lock | Kensington Lock Slot |
| Watch Dog | Yes |
| Operating Temperature | 0°C~40°C (-32℉~104℉) |
| Storage Temperature | -40℃~70℃ (-40℉~158℉) |
| Operating Humidity | 10%~90% non-condensing |
| Storage Humidity | 5%~90% non-condensing |
| Certificates |
CE, FCC, RoHS |
