TOTOLINK EX200 WX005 300Mbps Wireless N Range Extender

1* FE LAN port, 2*4dBi external antennas, 1*WPS button

- Complies with 802.11b/g/n standards.
- Up to 300Mbps date rate for Wi-Fi network.
- Two external antennas enhance the throughput’s stability.
- Portable and compact stylish design.
- Supports WPS (Wi-Fi Protected Setup) Wi-Fi extension by one-click.
- One Ethernet port for connecting wired devices to wireless network.
- Energy saving and environmental protection.


HARDWARE FEATURES

Interface

• 1 *10/100BaseTX (Auto MDI/MDIX) RJ45 port

Power Supply

• 5V /1A internal power

Antenna

• 2 *4dBi External Antennas

Button

• 1* WPS Button
• 1*RST Button

LED Indicators

• 1 *SYS
• 1* Wi-Fi

WIRELESS FEATURES

Standards

• IEEE 802.11n
• IEEE 802.11g
• IEEE 802.11b

RF Frequency

• 2.4~2.4835GHz

Data Rate

• Up to 300Mbps

EIRP

• < 20dBm

Wireless Security

• 64/128-bit WEP, WPA-PSK/WPA2-PSK (TKIP/AES)

Reception Sensitivity

• 11b 11M: - 81 dBm
• 11g 54M: - 68 dBm
• 11n HT20: - 65 dBm / HT40: - 62 dBm
• Others

Package Contents

• EX200 Wireless Extender *1
• Ethernet Cable *1
• Quick Installation Guide *1

Environment

• Operating Temperature: 0~40 Celsius
• Storage Temperature: -40~70 Celsius
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing
