Camera

Type of matrix

CMOS 1.3 megapixel 1/3 "progressive scan

Lens

3.6 mm

viewing angle

Gate

Auto / Manual 1/6 ~ 1/8000 with

Day / Night

The mechanical IR cut filter

infrared lights

to 30 m

white Balance

Auto / Manual

gain control

Auto / Manual

WDR

Digital

noise reduction

2D / 3D

Video

Maximum resolution

1280x960

compression algorithm

H.264, MJPEG

display speed

960P (1280x960) - 30 fps; 720P (1280x720) - 30 fps; D1 (720x576) - 25 fps

video Streams

2 stream

OSD

Time, camera name (up to 8 characters), user data

Motion Detector

Up to 2 zones

Privacy Masking

Up to 4 zones

Net

protocols

IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, Qos, DNS, DDNS, NTP, FTP, UPnP, HTTP

Compatibility methods

ONVIF

External interfaces

Network interface

10 / 100M Base-TX Ethernet

main

Food

12 VDC. current

Energy consumption

3.5 watts. (2 + W at the IR illumination)

Dimensions H x O

126 x 94 mm

Weight

0.33 kg

Working environment

-30 ° C ~ 60 ° C, rel. humidity less than 90%

protection class

IP66
