Camera

Sensor

1/3", 1.3 megapixel, progressive scanCMOS

Shutter

Auto/Manual, 1/6~1/8000 s

Lens

2.8 ~12 mm, F1.4

Zoom/Focus

Motor drive

Angle of View (H)

90° (wide)~28° (tele)

Min. Illumination

Colour: 0.03 Lux (F1.4, 50IRE)

Black & White: 0.01Lux (F1.4, 50IRE)

Day/Night

IR-cut filter with auto switch (ICR)

S/N

>50dB

IR

Smart-IR ,up to 30m (98 ft) IR range

Video

Max. Resolution

1280 × 960

Video Compression

H.264, MJPEG

Frame Rate

960P (1280*960) 30 fps; 720P (1280*720) 30 fps; D1 (720*576) 25 fps

9:16 Corridor Mode

Supported

ROI(Region of Interest)

Supported

Video Streaming

Triple

OSD

Up to 8 OSDs

Privacy Mask

Up to 8 areas

Audio

Audio Compression

G.711

Two-way audio

Supported

Storage

Edge Storage

Micro SD, up to 64 GB

Network

Protocols

L2TP,IPv4,IGMP,ICMP,ARP,TCP,UDP,DHCP,PPPoE,RTP,RTSP,Qos,NTP,FTP,HTTP,SNMP,SIP

Compatible Integration

ONVIF, IMOS,API

Interface

Audio I/O

3.5 mm audio interface

Input: impedance 35 kΩ; amplitude 2 V [p-p]

Output: impedance 600 Ω; amplitude 2 V [p-p]

Alarm I/O

2 / 1

Serial Port

1 RS485

Network

10M/100M Base-TX Ethernet

Video Output

1 BNC, impedance 75 Ω; amplitude 1 V [p-p]

General

Power

12 V DC, or PoE (IEEE802.3 af)

Power consumption: 4.5W (8.7W with IR on)

Dimensions (Ø x H)

Φ149 x 105 mm (Ø5.9” x 4.1”)

Weight

0.75 kg (1.7 lb)

Working Environment

-35°C ~ +60°C (-31°F ~ 140°F), Humidity ≤ 90% RH(non-condensing)

Vandal Resistant

IK10

Ingress Protection

IP66
