Camera

Sensor

1/3", 1.3 megapixel, progressive scan CMOS

Shutter

Auto/Manual, 1/6~1/8000 s

Lens

2.8~12 mm@F1.4; Angle of View (H): 90.0° (wide) ~28° (tele)

Zoom/Focus

Manual

Min. Illumination

Colour: 0.002 Lux (F1.4, AGC ON)

0 Lux with IR

Day/Night

IR-cut filter with auto switch (ICR)

IR Range

Up to 30m (98 ft) IR range

S/N

>50dB

WDR

120dB

Digital WDR

Video

Max. Resolution

1280 × 960

Video Compression

H.264,MJPEG

Capture Collect Mode

960P (1280×960): Max. 30 fps; 720P (1280×720): Max. 30 fps; D1 (720×576): Max. 25 fps

9:16 Corridor Mode

Supported

ROI

Supported

Video Streaming

Triple

OSD

Up to 8 OSDs

Privacy Mask

Up to 4 areas

Audio

Audio Compression

G.711

N/A

Two-way audio

Supported

N/A

Storage

Edge Storage

Micro SD, up to 128 GB

Network

Protocols

L2TP,IPv4,IGMP,ICMP,ARP,TCP,UDP,DHCP,PPPoE,RTP,RTSP,Qos,NTP,FTP,HTTP,SNMP,SIP

Compatible Integration

ONVIF, API

Interface

Audio I/O

audio cable

N/A

Input: impedance 35 kΩ; amplitude 2 V [p-p]

N/A

Output: impedance 600 Ω; amplitude 2 V [p-p]

N/A

Alarm I/O

1/ 1

N/A

Network

1 RJ45 10M/100M Base-TX Ethernet

Video Output

1 BNC, impedance 75 Ω; amplitude 1 V [p-p]

N/A

Reset

1 Reset Button

Power Output

DC12V Power Output With PoE

General

Power

12 V DC, or PoE (IEEE802.3 af)

Power consumption: max.6.6 W (PoE :max.7.2 W)

Dimensions (Ø x H)

Φ148 x 111.3 mm (Ø5.8” x 4.4”)

Weight

0.75 kg (1.7 lb)

Working Environment

-40°C ~ +60°C (-40°F ~ 140°F), Humidity ≤ 90% RH(non-condensing)

Vandal Resistant

IK10

Ingress Protection

IP66
