Camera

Sensor

1/3", 1.3 megapixel, progressive scan CMOS

Shutter

Auto/Manual, 1/6~1/8000 s

Lens

7~22 mm@F1.4; Angle of View (H): 38° ~ 12°

Zoom/Focus

Manual

Min. Illumination

Colour: 0.02 Lux (F1.4, 50IRE)

Black & White: 0.008Lux (F1.4, 50IRE)

Day/Night

IR-cut filter with auto switch (ICR)

S/N

>50dB

WDR

120 dB

IR

Smart-IR ,up to 50m (164 ft) IR range

Video

Max. Resolution

1280 × 960

Video Compression

H.264,MJPEG

Frame Rate

960P (1280*960) 30 fps; 720P (1280*720) 30 fps; D1 (720*576) 25 fps

9:16 Corridor Mode

Supported

ROI

Supported

Video Streaming

Triple

OSD

Up to 8 OSDs

Privacy Mask

Up to 4 areas

Audio

Audio Compression

G.711

Two-way audio

Supported

Storage

Edge Storage

Micro SD, up to 64 GB

Network

Protocols

L2TP,IPv4,IGMP,ICMP,ARP,TCP,UDP,DHCP,PPPoE,RTP,RTSP,Qos,NTP,FTP,HTTP,SNMP,SIP

Compatible Integration

ONVIF, IMOS,API

Interface

Audio I/O

3.5 mm audio interface

Input: impedance 35 kΩ; amplitude 2 V [p-p]

Output: impedance 600 Ω; amplitude 2 V [p-p]

Alarm I/O

2 / 1

Serial Port

1 RS485

Network

10M/100M Base-TX Ethernet

Video Output

1 BNC, impedance 75 Ω; amplitude 1 V [p-p]

General

Power

12 V DC, 24 V AC or PoE (IEEE802.3 af)

Power consumption: 4.5 W (11W with IR on)

Dimensions (L × W × H)

282.6 ×90 ×86 mm (11.1” × 3.5” × 3.4”)

Weight

1.2 kg (2.6 lb)

Working Environment

–40°C ~ +60°C (-40°F ~ 140°F), Humidity ≤ 90% RH(non-condensing)

Ingress Protection

IP66
