Optics
Compression
Network
Structure
| Camera | |||||
| Sensor | 1/3", 1.3 Megapixel, progressive scan, CMOS | ||||
| Lens | 3.6mm@F1.8(6mm, 12mm optional); Angle of view(H): 76.7° (46.9° / 24.2°) | ||||
| Shutter | Auto/Manual, 1/6~1/8000 s | ||||
| Day/Night | IR-cut filter with auto switch (ICR) | ||||
| IR | Up to 30m (98 ft) IR range | ||||
| AWB(Auto white balance) | Auto/manual | ||||
| Gain Control | Auto/manual | ||||
| WDR | Digital | ||||
| Noise Reduction | 2D/3D | ||||
| Video | |||||
| Max. Resolution | 1280×960 | ||||
| Video Compression | H.264/MJPEG | ||||
| Frame Rate | 960P (1280*960): Max. 30 fps; 720P (1280*720): Max. 30 fps; D1 (720*576): Max. 25 fps | ||||
| Video Streaming | Dual | ||||
| OSD | Up to 8 OSDs | ||||
| Motion Detection | Up to 2 areas | ||||
| Privacy Mask | Up to 4 areas | ||||
| Network | |||||
| Protocols | IPv4,IGMP,ICMP,ARP,TCP,UDP,DHCP,RTP,RTSP,Qos,DNS,DDNS,NTP,FTP,UPnP,HTTP | ||||
| Compatible Integration | ONVIF | ||||
| Interface | |||||
| Network | 10M/100M Base-TX Ethernet | ||||
| General | |||||
| Power Supply | 12 V DC, or PoE (IEEE802.3 af) | ||||
| 3.5 W (with IR on: extra 2 W) | |||||
| Material | Cast aluminum | ||||
| Dimensions (L × W × H) | 146 × 82.4 ×71.7 mm (5.7” × ϯ.2” × 2.8”Ϳ | ||||
| Weight | 0.48 kg (1.06 lb) | ||||
| Working Environment | -30°C ~ +60°C (-22°F ~ ϭϰϬ°FͿ, Huŵidity ≤ 9Ϭ% RH;ŶoŶ-condensing) | ||||
| Ingress Protection | IP66 | ||||
