Tenda PSE30G-AT 802.3at Gigabit PoE Injector





Compatible with IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3af、IEEE802.3at Standard



Transmission distance up to 100 Meters Overvoltage, overcurrent and overload proctection Plug and play



The PoE injector PSE30G-AT can directly provide dc power to equipment which need power supply, plug and play, convenient for network construction, Date&Power Out port maximum output power of 30 w. PSE30G-AT can auto-start short-circuit function to cut off power supply when meet too high current or electricity interruption, to prevent equipment burnout and avoid networking failure caused by electricity interruption or installing error. This function make PSE30G-AT can be widely applied to wireless network devices, bluetooth, IP-telephone which compliant with IEEE802.3af/at. Matched with Ethernet/Power separator to change the current networking into source LAN, easy management, strengthen controlling and decrease the maintenance cost.



Standard and protocol supported Compatible with IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3af , IEEE802.3atStandard

CSMA/CD, TCP/IP

Features Support the powered devices compatible with IEEE802.3af、IEEE802.3at Standard

Transmission range up to 100M

Power output can be matched automatically

Plug and play

Port 1 GE port

1 data&power output port supporting PoE

Indicators PWR, PoE

Dimension(W*D*H) 131mm*60mm*33mm

Power output 30.6W

Operating temperature 0℃~40℃

Storage temperature -40℃~70℃

Relative humidity(Operational) 10%~90% (noncondensing)

Relative humidity(Storage) 5%~90% (noncondensing)
