• 2 Megapixel high-performance CMOS
• Analog HD output, up to 1080P resolution
• True Day/Night
• OSD menu, DNR, Smart IR
• True WDR, up to 120dB
• EXIR 2.0, up to 20m IR distance
• IP67
• Up the Coax(HIKVISION-C)
• PoC.af
| Camera | ||
|---|---|---|
| Image Sensor: | | | 2MP CMOS Image Sensor |
| Signal System: | | | PAL/NTSC |
| Effective Pixels: | | | 1920(H)*1080(V) |
| Shutter Time: | | | 1/25(1/30) s to 1/50,000 s |
| Lens Mount: | | | M12 |
| Adjustment Range: | | | Pan: 0 - 360°, Tilt: 0 - 90°, Rotation: 0 - 360° |
| Day& Night: | | | IR cut filter with auto switch |
| Wide Dynamic Range: | | | 120dB |
| Video Frame Rate: | | | 1080p@25fps/1080p@30fps |
| HD Video Output: | | | 1 Analog HD output |
| Synchronization: | | | Internal Synchronization |
| Up the Coax: | | | Support |
| Menu | ||
| Auto White Balance: | | | Auto/MWB |
| BLC: | | | Support |
| AGC: | | | Support |
| Language: | | | English/Chinese |
| General | ||
| Operating Conditions: | | |
-40 °C - 60 °C (-40 °F - 140 °F) Humidity 90% or less (non-condensing) |
| Power Supply: | | | 12 VDC±25%/PoC.af |
| Weather Proof: | | | IP67 |
| IR Range: | | | Up to 20m |
| Communication : | | |
Up the coax Protocol: HIKVISION-C(Coaxitron) |
| Dimension: | | | 58 mm × 61 mm × 163 mm (2.28" × 2.40" × 6.42") |
