·Full-color starlight
·40m LED distance
·Max. 30fps@1080P
·CVI/CVBS/AHD/TVI switchable
·Built-in mic(-A)
·3.6mm fixed lens
·IP67, 12V±30% DC
2.16 megapixel 1 / 2.8 ”CMOS sensor.
Digital resolution 1080P (1920x1080), 720P (1280x720), 960H (960x576).
Images per second.
CVI 25 ips @ 1080P, 25/50 ips @ 720P.
TVI 25 ips @ 1080P, 25/50 ips @ 720P.
AHD 25 ips @ 1080P / 720.
4-in-1 output switchable via OSD or UTC PFM820.
0.005 lux F16 (30IRE) / 0 lux White LED On.
White lighting 2 leds, 40 meters.
Fixed 3.6mm lens.
Angle of view 86.9 ° (H), 46.3 ° (V), 103.6 ° (D).
16X digital zoom.
OSD through coaxial (up to 800 meters).
Automatic and manual white balance.
Automatic and manual gain control.
Backlight compensation BLC, HLC.
Digital WDR.
2D-NR noise reduction.
Electronic defog.
Mirror mode.
Privacy mask with 4 rectangular areas.
It incorporates a microphone.
12 VDC supply (± 30%).
Consumption 4.2W (max).
Operating temperature from -40 ° C to + 60 ° C.
Storage temperature from -40 ° C to + 60 ° C.
Relative humidity <95% (without condensation).
Protection degree IP67.
Metal housing.
Dimensions Ø106 x 93.6 (H) mm.
Weight 460 g.
3AXIS 0 ° to 360 ° (PAN), 0 ° to 78 ° (TILT), 0 ° to 360 ° (Rotation).
