-CPU: Amlogic S905Y2 ARM Cortex-A53 Quad core 64bit
-GPU:  Dalvin MP2
-OS: Android 8.1
-RAM: DDR4 2GB/4GB
-ROM: eMMC 16GB/32GB
-Wifi: IEEE 802.11 b/g/n
-HD: 4K*2K UHD Output, HD 2.0A
-Storage Extension:Support MicroSD(TF) ，Up to 32GB



CPU     Amlogic S905Y2 Quad Core ARM Cortex A53 2GHz
GPU     ARM Dvalin MP2 GPU
Memory     LowPower DDR4: 2GB
Flash     eMMC：16GB
WiFi     IEEE 802.11 a/b/g/n/ac ;  2.4G / 5.8G
BT      BT 4.2
Moudle     Plastic : Black  Color
I/O     1*HD     HD 2.1 ,Support HD CEC, Dynamic HDR and HDCP 2.2,4Kx2K 75 max resolution output.
1*USB，1*Micro USB     1* USB 3.0  ;1*Micro USB 2.0
1*IR      Remote Reciver Connect
1*TF CARD     Support 4GB/8GB/16GB/32GB/64GB
Power     DC 5V/1A；LED indicator，Working ：Blue;
Software
OS     Android 8.1
Video     Ÿ  Amlogic Video Engine (AVE) with dedicated hardware decoders and encoders
Ÿ  Support multi-video decoder up to 4Kx2K60fps+1x1080P60fps
Ÿ  Supports multiple “secured” video decoding sessions and simultaneous decoding and encoding
Ÿ  Video/Picture Decoding
-  VP9 Profile-2 up to 4Kx2K60fps
-  H.265 HEVC MP-10L5.1 up to 4Kx2K60fps
-  AVS2-P2 Profile up to 4Kx2K60fps
-  H.264 AVC HPL5.1 up to 4Kx2K30fps
-  H.264 MVC up to 1080P60fps
-  MPEG-4 ASPL5 up to 1080P60fps (ISO-14496)
-  WMV/VC-1 SP/MP/AP up to 1080P60fps
-  AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P60fps
-  MPEG-2 MP/HL up to 1080P60fps (ISO-13818)
-  MPEG-1 MP/HL up to 1080P60fps (ISO-11172)
-  RealVideo 8/9/10 up to 1080P60fps
-  Multiple language and multiple format sub-title video support
-  MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918)
-  Supports JPEG thumbnail, scaling, rotation and transition effects
-  Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *.iso, *.mp4, *.rm and *.jpg file formats
Audio     Supports MP3, AAC, WMA, RM, FLAC, Ogg and programmable with 7.1/5.1 down-mixing
Built-in serial digital audio SPDIF/IEC958 input/output and PCM input/output
built-in TDM/PCM/I2S ports with TDM/PCM mode up to 384kHz x32bits x 8ch or 96kHz x 32bits x 32ch and I2S mode up to 384kHz x 32bits x 8ch
Digital microphone PDM input with programmable CIC, LPF & HPF, support up to 8 DMICs
Built-in stereo audio DAC
Supports concurrent dual audio stereo channel output with combination of analog+PCM or I2S+PCM
Image     HD JPEG、BMP、GIF、PNG、TIF
Language     English French German Spanish Italian etc multilateral languages

Accesscries
1、HD cable  *1
2、IR Line *1
3、IR Remote *1
6、Micro USB Line  *1
6、USB adapter  *1
4、User Manual *1
5、Package box  *1




1 year warranty
