Type
Desktop
Writing Method
Semiconductor Laser
Main Function
Copy, Print, Scan, Fax
Warm Up Time
20 seconds
CPU
Power PC 465S 1.0 GHz
Memory
Standard 1GB (Max. 2GB)
Paper Capacity, Standard
500 sheets (Cassette) + 100 sheets (MPT)
Paper Capacity, Maximum
3,100 sheets (Main Unit + PF-5120 + PF-5140 + MPT)
Paper Size, Cassette
Min. A6R - Max. A4 (Legal)
Paper Size, Option
Min. A6R - Max. A4 (Legal)
Paper Size, MPT
Min. A6R - Max. A4 (Legal)
Paper Weight, Cassette
60 - 220 g/m²
Paper Weight, Option
60 - 220 g/m²
Paper Weight, MPT
60 - 220 g/m²
Output Capacity
Max. 500 sheets face-down
Duplex Printing
Paper size: A5R – A4 (Legal);
Paper weight: 60 - 220 g/m²
Document Processor
Standard (Max. 75 sheets RADF Type)
Control Panel
4.3 inch Color Touch LCD Panel
Power Consumption (Standard configuration), Copy/Print Mode
533W or less
Power Consumption (Standard configuration), Stand-by Mode
77W or less
Power Consumption (Standard configuration), Energy Saver
2.5W or less
Noise (ISO7779/ ISO9296), Copy/Print Mode
49.5dB(A)
Noise (ISO7779/ ISO9296), Stand-by Mode
30dB(A)
Dimension (W x D x H) (Main Unit)
550mm x 507.5mm x 736.6mm
Weight (Main Unit)
Approx. 48 kg
