| ardware configuration | CPU | RK3566 Quad core 64-bit Cortex-A55 Frequency:1.8GHZ |
| GPU | Mali-G52-2EE, Supports OpenGL ES 3.2/2.0/1.0 | |
| FLASH | 64GB | |
| SDRAM | 8GB | |
| WIFI/BT | 2.4GHZ&5GHZ WIFI, Bluetooth 4.0 | |
| ETHERNET | Standard 10/100/1000M RJ-45 | |
| HDMI | HDMI 2.0, 4Kx2K@60fps max resolution output | |
| USB host | Universal Serial Bus 2.0 *1, High speed USB3.0 *1 | |
| SPDIF | Audio Digital Interface | |
| Card reader | TF card | |
| Power Supply | Power Supply | DC 5V/2A |
| CPU Engine | 2D | Hardware 2D graphics acceleration |
| Video Decoder |
•H.265 HEVC/MVC Main10 Profile yuv420@L5.1 up to 4096×2304@60fps
•H.264 AVC/MVC Main10 Profile yuv400/yuv420/yuv422/@L5.1 up to 4096×2304@60fps •VP9 Profile0/2 yuv420@L5.1 up to 4096×2304@60fps •VP8 verision2,up to 1920×1088@60fps •VC1 Simple Profile@low, medium, high levels, Main Profile@low, medium, high levels, Advanced Profile@level0~3,up to 1920×1088@60fps •MPEG-4 Simple Profile@L0~6,Advanced Simple Profile@L0~5,up to 1920×1088@60fps •H.263 Profile0,levels 10-70,up to 720×576@60fps |
|
| Video Encoder |
•H.264/AVC BP/MP/HP@level4.2,up to 1920×1080@100fps
•H.265/HEVC MP@level4.1, up to 1920×1080@100fps (4096×4096@10fps with TILE) •Support YUV/RGB video source with rotation and mirror |
|
| JPEG decoder |
•Decoder size is from 48×48 to 65536×65536
•Support YUV400/YUV411/YUV420/YUV422/YUV440/YUV444 •Support 1920×1080@120fps •Support MJPEG |
|
| Software Specifications | OS | Android 11.0 |
| Preinstalled | Preinstalled KDplayer, Youtube, Google play store, Chrome | |
| HDD file system | FAT16/FAT32/NTFS | |
| Languages | English/French/German/Spanish/Italian/ etc multilateral languages |
