Suprema XPD2-MDB-Rev.2 outdoor compact RFID reader



Xpass D2 external compact RFID reader. Supports most types of single-device RFID card standards, including 125 Khz EM, Wiegand format card, 13.56 MHz MIFARE, MIFARE Plus, DESFire EV1 / EV2 (DESFire EV2 cards are supported by being backward compatible with DESFire EV1 cards) , FeliCa and can read mobile cards using NFC and BLE. Suitable for outdoor installation (IP67/IK08), moisture-proof, dust-proof and vandal-proof. Combined with Suprema's smart biometric controller, the CoreStation, the XPass D2 complements the biometric-driven access control system with an improved simplicity and security level of the centralized system topology. Supports RS-485 (OSDP compatible, Slave) and Wiegand interface. Power supply: DC 12V (not included). At 48mm wide, it is perfect for installations in tight spaces and narrow door frames. Operating temperature from -35C to +650C. Weight: 117 g. Dimensions (WxHxD): 48x144.7x27mm. Supports tamper, 3-channel LED, buzzer.
