SUPERMICRO HDD-T12T-HUH721212ALE600 HGST 3.5" 12TB SATA 6Gb/s 7.2K RPM 256M0F30144 512e ISE
Disk configuration
Device location Internal
Form factor 3.5 "
Storage device capacity 12 TB
Supported data channel SATA III-600
Installed cache capacity 256 MB
Maximum capacity of sectors 512 B
Productivity
Rotation speed 7200 rpm
Average rotation delay 4.16 ms
Average search time 8 ms
Maximum search time 8.6 ms
Supported external data transfer rate 6 Gbps
Reliability
Irrecoverable errors 1 per 10 ^ 15
Average time between damages 2500000 hr
Hard drive features 24/7
HelioSeal Technology
Impact resistance when working 70G @ 2ms
Shock resistance when stored 300G @ 2ms
Vibration tolerance at work 0.67G @ 5-500Hz
Vibration tolerance for storage 1.04G @ 2-200Hz
Supported interfaces
SATA III 1
Energy consumption
Rated supply voltage 5 V
Maximum supply voltage 12 V
Minimum supply voltage 5 V
Maximum power consumption 7.2 W
Minimum power consumption 5.3 W
Operating conditions
Max. operating ambient temperature 60 V ° C
Min. operating ambient temperature 5 V ° C
Typical operating noise level 36 dB
Dimensions and weight
Depth 147 mm
Height 26.1 mm
Width 101.6 mm
Nominal weight 0.66 kg
Other features
Package type With packaging
Warranty
Warranty products - refundable Yes
Warranty validity criteria Serial number
Logistic information
Package weight - Gross (kg) 2 kg
Package weight - Net (kg) 0 kg
