SF-3600GC Sat finder Support DVB S/S2 CCTV Camera test 3.5''TFT LCD Screen

199.00 €
Συμπεριλαμβάνεται Φ.Π.Α. 20%
χωρίς τα έξοδα αποστολής

Κωδικός: 11084

Βάρος: 0.600 kg
Μη Διαθέσιμο

Τεχνικά Στοιχεία Βασικά Στοιχεία Αξιολόγηση

Features:

Support DVB-S2
3.5''TFT LCD
Multi-lingual OSD and use-friendly UI
Support Spectrum function
Real time constellation display
Support TP search ,NIT search and blindly search
Measurement Type: strength,quality,C/N,BER,FEC,
MER,TP MOD
USB 2.0 for software update/media play back
Support PVR
Support program edit (move/skip/lock/delete/rename)
Support electronic program guide (EPG)
Very easy to use with shortcut key
Build in loudspeaker for audio play
Visual and audible signal when signal received
Large lithium battery capacity(2200mAh)
Supports AV/HD TV output
Support signal input such as TVI CVI AHD, the default
model only supports CVBS.
Equipped with LED energy-saving lighting
.2 Accessories:
Manual x1
Power Adapter x1
AV Cable（CVBS/L DC2.1）x1
Connector F to F type x1
Connector BNC to AV x1
Device Bag x1

System Resources
*Main Processor*	*600M Hz based CPU*
*Flash Memory*	*32M Bits*
*DDR2 SDRAM*	*512M Bits*
Tuner/Front-end
*Tuner Type*	*DVB-S/DVB-S2*
*Input Connector*	*F-type*
*Frequency Range*	*950MHz~2150MHz*
*Signal Level*	*-65~-25dBm*
*Impedance*	*75Ω*
*LNB Power & Polarization*	*Vertical:+13V*
	*Horizontal:+18V*
	*Current:Max.500mA*
	*Overload Protection*
*DiSEqC Control*	*Version 1.0/1.1/1.2/1.3,USALS Available*
*22KHz Tone*	*Frequency:22±1KHz*
*Demodulation*	*QPSK,8PSK,16APSK,32APSK*
*Symbol Rate*	*1~60Msps*
*Power Supply*
*Input Voltage Adapter*	*Free Voltage (100~240V AC 50/60Hz)*
*Power Consumption*	*10W MAX*
*Power charger output*	*14V DC 2A*
*Battery*	*12.6V/2200mAh*
*Battery charging time*	6H
*Battery standard discharging time*	*3-4H*
*CCTV input*	*CVBS(SF-3600G) CVBS/ TVI /CVI /AHD(SF-3600GC)*
*Video Output*	*RCA(CVBS, L), HD TV Interface*
*Power Output*	*DC12V*
*Audio output*	*Built-in Loudspeaker*
*USB*	**1USB 2.0 slot Compatible for Host***
*Transport Stream*	*MPEG-2/4,H.264*
