SEAGATE SSD BarraCuda 510 (M.2 2280/256 GB/ PCIe Gen3 x4, NVMe) ZP256CM30041
Disk configuration
Device location Internal
Form factor M.2 (2280)
Storage device capacity 256 GB
Supported PCIe NVMe 3.0 x4 data channel
NAND Flash memory technology
Triple-Level Cell flash memory technology
Productivity
Maximum Random Read Rate 180000 IOPS
Maximum Random Write Rate 260000 IOPS
Maximum Sequential Read Rate 3100 MB / s
Maximum Sequential Write Rate 1050 MB / s
Total Bytes Written (TBW) 160 TB
Supported interfaces
M.2 Interface Quantity 1
Reliability
Average time between damages 1800000 hr
Solid State Drive Features TRIM Support
Supported standards S.M.A.R.T.
Impact resistance when working 1500G @ 0.5ms
Energy consumption
Maximum power consumption 3 W
Operating conditions
Max. operating ambient temperature 70 V ° C
Min. operating ambient temperature 0 V ° C
Max. ambient temperature in off mode 85 V ° C
Min. non-operating ambient temperature -40 V ° C
Dimensions and weight
Depth 80.15 mm
Height 2.23 mm
Width 22.15 mm
Box type package
Warranty
Warranty products - refundable Yes
Warranty validity criteria Serial number
Logistic information
Package weight - Gross (kg) 0.06 kg
Package weight - Net (kg) 0.61 kg
Number in package 1
Carton weight - Gross (kg) 0.91 kg
Retail Packaging Net Weight Carton 0.91 kg
Retail Packaging Net Weight Plastic 0.03 kg
Packages in a carton 10
EAN code 8719706016612
