PALIT 4710562242263_3Y GeForce RTX 3060 Ti
Palit GeForce RTX 3060Ti Dual 8GB GDDR6, NE6306T019P2-190AD
Video output
PCI Express 4.0 x16 expansion slot required
NVIDIA GeForce 3060 Ti video card chipset
GPU - Core name GA104-200-A1
GPU core speed 1410 MHz
GPU Core Speed Boost 1665 MHz
Number of GPUs 1
Number of thread processes 4864
Texture Mapping Unit Quantity 152
Render Output Units Quantity (ROP) 80
Tensor Core Quantity 152
Ray-tracing Cores Quantity 38
Maximum resolution 7680x4320
2D/3D features HDCP(High-Bandwidth Digital Content Protection)
Nvidia CUDA
Nvidia GPU Boost
Nvidia Adaptive V-Sync
Nvidia G-Sync
Nvidia ShadowPlay
VR Ready
Nvidia Ansel
Shader Model 6.1
Nvidia DLSS
Nvidia Highlights
NVIDIA FreeStyle
NVIDIA Game Ready
NVIDIA Studio
API support OpenCL 1.2
DirectX 12.0
OpenGL 4.6
Vulkan 1.2
Memory
Video memory type Video card memory
Memory type GDDR6 SDRAM
Installed video memory 8 GB
Video memory speed 14000 MHz
Memory bus capacity 256 bit
Memory channel width 448 GB/s
Supported interfaces
Number of HDMI interfaces 2
Type HDMI Interface Connectors HDMI (Type-A)
Number of monitor interface connectors 3
System Requirements
External Power 8 pin
Required power supply 550 W
Other features
Cooling system - type VGA Cooler
Card Slot Width 2 slots
Features of a video card RGB LED
Included Accessories Quick User Guide
Cables included Power cord
Dimensions and weight
Depth 247 mm
Height 40 mm
Width 120 mm
Warranty
Warranty products - subject to return Yes
Warranty Validity Criteria Serial Number
Logistics information
Package Weight - Gross (kg) 0.1 kg
Package Weight - Net (kg) 0.1 kg
Quantity per pack 1
Carton weight - Gross (kg) 0.1 kg
Retail Packaging Net Weight Carton 0.1 kg
Retail Packaging Net Weight Plastic 0.1 kg
Packages in Carton 1
Package type With packaging
