MSI RX 6700 XT MECH 2X 12G Radeon RX 6700 XT



MSI Video Card AMD Radeon RX 6700 XT MECH 2X 12G, 12GB GDDR6, 192-bit, 384.0 GB/s, 16000 MHz Effective Memory Clock, Boost: 2581 MHz, 2560 Cores, PCIe 4.0, 3x DP 1.4, HDMI 2.1, 650W Recommended PSU, 3Y



Video output

PCI Express 4.0 x16 expansion slot required

AMD Radeon RX 6700 XT video card chipset

GPU - Core Name NAVI 21

GPU core speed 2321 MHz

GPU Core Speed ​​Boost 2581 MHz

Number of GPUs 1

Number of thread processes 2560

Texture Mapping Unit Quantity 160

Render Output Units Quantity (ROP) 64

Max. Monitors Supports 4

Maximum resolution 7680x4320

2D/3D features AMD CrossFire

AMD Radeon Boost

RDNA 2 Architecture

OpenCL API support

DirectX 12.0

OpenGL 4.6

Fill Rate (textures) 413 GT/s

Fill rate (pixels) 165.2 GP/s

Memory

Video memory type Video card memory

Memory type GDDR6 SDRAM

Installed video memory 12 GB

Video memory speed 16 Gbps

Memory bus capacity 192 bit

Memory channel width 384 GB/s

Supported interfaces

Number of HDMI interfaces 1

Type HDMI Interface Connectors HDMI (Type-A)

Number of monitor interface connectors 3

System Requirements

External Power 2 x 8 pin

Required power supply 650 W

Other features

Cooling system - type TORX 3.0 Fan

Card Slot Width 2 slots

Included accessories User manual

Dimensions & weight

Depth 247 mm

Height 51 mm

Width 131 mm

Nominal weight 921 g

Warranty

Warranty products - subject to return Yes

Warranty Validity Criteria Serial Number

Logistics information

Package Weight - Gross (kg) 1.51 kg

Package Weight - Net (kg) 1.38 kg

Quantity per pack 1

Carton weight - Gross (kg) 15.15 kg

Retail Packaging Net Weight Carton 0.135 kg

Retail Packaging Net Weight Plastic 0.135 kg

Packages in carton 4

Package type Box
