MSI PRO_H410M-B H410



MSI PRO H410M-B, mATX, Socket 1200, Dual Channel DDR4 2933MHz, 1x PCIe 3.0 x16 slot, 1x M.2 slot, 1x VGA, 1x HDMI, 2x USB 3.2 Gen 1, 4x USB 2.0, 7.1 HD Audio, 1Gbps LAN, 3Y



Main Board Desktop - Processor

Intel H410 motherboard chipset

Intel Celeron processor

Intel Pentium

Intel 10th Gen Processors

Socket 1200 processor socket

Max. number of installed processors 1

Main Board Desktop - Memory

Memory type DDR4 SDRAM

Memory form factor DIMM 288-pin

Memory Speed/Frequency 2133MHz(PC4-17000)

2666MHz(PC4-21300)

2933MHz(PC4-23400)

Maximum amount of installed memory 64 GB

Total number of memory slots 2

Offers a non-ECC error checking method

Memory Features Two DDR Channels

Unbuffered

XMP

Controller

Built-in Storage Controller:

PCIe 3.0 x4/SATA (1 x M.2 (Key M))

Storage Controller:

SATA III-600 (4)

Main Board Desktop - Audio Output

Audio integrated Yes

Device Location Built-in

Realtek ALC892/ALC897 audio chipset

Audio output type 7.1 channel surround

Compatible audio standards High Definition Audio

Main Board Desktop - Networking Specifications

LAN integrated Yes

Supported data exchange protocols Gigabit Ethernet/Fast Ethernet/Ethernet

Slots provided

PCI Express 3.0 x16 1

PCI Express 3.0 x1 1

Supported interfaces

PS/2 1

LAN 1 (RJ-45)

VGA 1 (15-pin D-sub)

HDMI 1 (HDMI (Type A))

USB 3.2 Gen 1 2 (USB 3.2 (type A))

USB 2.0 4 (USB 2.0 (type A))

Audio interface 3 (3.5 mm mini jack)

Desktop Motherboard - Features

Power connector type 24+8 pin

Main Board Desktop - Software

Microsoft Windows 10 64-bit operating system supported

Other features

Cables included 2 x SATA cables

I/O Shield accessories included

User manual

Driver CD

Main Board Desktop - Dimensions&Weight

Micro ATX form factor

Height 202 mm

Width 236 mm

Warranty

Warranty products - subject to return Yes

Warranty Validity Criteria Serial Number

Logistics information

Package Weight - Gross (kg) 1 kg

Package Weight - Net (kg) 1 kg

Quantity per pack 1

Carton weight - Gross (kg) 1 kg

Retail Packaging Net Weight Carton 0.5 kg

Retail Packaging Net Weight Plastic 0.5 kg

Packages in Carton 1

Package type Box

EAN code 4719072917395
