MSI PRO_B660M-E_DDR4 B660



MSI PRO B660-A DDR4, ATX, Socket 1700, Dual Channel DDR4 4800(OC)MHz, 2x PCIe x16 slots, 2x M.2 slots, 1x HDMI, 1x DP, 1x VGA, 2x USB 3.2 Gen 2, 4x USB 2.0, Type-C, 7.1 HD Audio, 2.5Gpbs LAN, 3Y



Main Board Desktop - Processor

Intel B660 motherboard chipset

Processor Intel 12th Gen Processors

Socket 1700 processor socket

Max. number of installed processors 1

Main Board Desktop - Memory

Memory type DDR4 SDRAM

Memory form factor DIMM 288-pin

Memory Speed/Frequency 2133MHz(PC4-17000)

2666MHz(PC4-21300)

3200MHz(PC4-25600)

Maximum amount of installed memory 128 GB

Total number of memory slots 4

Offers a non-ECC error checking method

Memory Features Two DDR Channels

Unbuffered

Dual Rank

Single Rank

XMP

Controller

Built-in Storage Controller:

Supports: Level 0, Level 1, Level 10, Level 5

SATA III-600 (4)

Storage Controller:

PCIe 4.0 x4/SATA (1 x M.2 (Key M))

Storage Controller:

PCI Express 4.0 x4 (1 x M.2 (Key M))

Support Wi-Fi Controller:

1 x M.2 (Key E)

Main Board Desktop - Audio Output

Audio integrated Yes

Device Location Built-in

Audio chipset Realtek ALC897

Audio output type 7.1 channel surround

Compatible audio standards High Definition Audio

Main Board Desktop - Networking Specifications

LAN integrated Yes

Realtek Dragon RTL8125BG network card chipset

Supported data exchange protocols Gigabit Ethernet/Fast Ethernet/Ethernet

2.5 Gbps

Slots provided

PCI Express 4.0 x16 1

PCI Express 3.0 x4 1

PCI Express 3.0 x1 3

Supported interfaces

USB 2.0 4 (USB 2.0 (type A))

USB 3.2 Gen 2 2 (USB 3.2 (type A)); 2 (USB 3.2 (type C))

DisplayPort 1

HDMI 2.0 1 (HDMI (Type A))

VGA 1 (15-pin D-sub)

Audio interface 5 (3.5 mm mini jack)

S/PDIF-out Optical 1 (TOSLINK)

LAN 1 (RJ-45)

Desktop Motherboard - Features

Power connector type 24+8+4 pin

Motherboard - features Intel Optane Memory Ready

Intel Smart Response Technology Support

Other features

Cables included 2 x SATA cables

I/O Shield accessories included

User manual

Screws

Driver CD

Main Board Desktop - Dimensions&Weight

ATX form factor

Height 244 mm

Width 305 mm

Warranty

Warranty products - subject to return Yes

Warranty Validity Criteria Serial Number

Logistics information

Package Weight - Gross (kg) 1.5 kg

Package Weight - Net (kg) 1.5 kg

Quantity per pack 1

Carton weight - Gross (kg) 1.5 kg

Retail Packaging Net Weight Carton 0.5 kg

Retail Packaging Net Weight Plastic 0.5 kg

Packages in Carton 1

Package type Box

EAN code 4719072912451
