Printer TypeWorkgroup printer - laser - color

ManufacturerKyocera

POWER DEVICE

Typepower supply

Nominal VoltageAC 120 V

Frequency Required60 Hz

Power Consumption Operational469 Watt

Power Consumption Stand by55 Watt

Power Consumption Sleep0.6 Watt

Form Factorinternal

CONNECTIVITY

Mobile Printing CapabilityApple AirPrint

PRINTER

Print SpeedUp to 32 ppm - B/W - Letter A Size (8.5 in x 11 in)

Up to 32 ppm - color - Letter A Size (8.5 in x 11 in)

Up to 30 ppm - B/W - A4 (8.25 in x 11.7 in)

Up to 30 ppm - color - A4 (8.25 in x 11.7 in)

Up to 26 ppm - B/W - Legal (8.5 in x 14 in)

Up to 26 ppm - color - Legal (8.5 in x 14 in)

Built-in Devicesstatus LCD

Connectivity Technologywired

InterfaceUSB 2.0, Gigabit LAN, USB host

AirPrint EnabledYes

Automatic DuplexingYes

PostScript Supportstandard

First Print Out Time B/W7 sec

Language SimulationKPDL3, PCL 5C, PCL 6, PCL XL, PDF Direct, PRESCRIBE IIc, PostScript 3, XPS

Color Management FeaturesMopria

Printer FeaturesKyocera ECOSYS Technology

Media Handling100-sheet multipurpose tray, 500-sheet input tray

Typeworkgroup printer

Min H-Document Size2.76 in

Min V-Document Size5.83 in

Max H-Document Size8.5 m

Max V-Document Size14 in

Media Typeplain paper

Media SizesA4 (8.25 in x 11.7 in), A5 (5.83 in x 8.25 in), A6 (4.13 in x 5.83 in), B5 (6.93 in x 9.83 in), B6 (4.92 in x 6.93 in), Folio (8.5 in x 13 in), Legal (8.5 in x 14 in), Letter A Size (8.5 in x 11 in)

Min Media Weight60 g/m²

Max Media Weight220 g/m²

Total Media Capacity600 sheets

POWER

Frequency Required60 Hz

Power Consumption Sleep0.6 Watt

Power Consumption Operational469 Watt

MISCELLANEOUS

Consumables Included1 x toner cartridge (black) - up to 3500 pages

1 x toner cartridge (cyan) - up to 2500 pages

1 x toner cartridge (magenta) - up to 2500 pages

1 x toner cartridge (yellow) - up to 2500 pages

Color Categorygray, white

PROCESSOR

TypeCortex-A9

ManufacturerARM

Clock Speed1.2 GHz

NETWORKING

NetworkingPrint server

Remote Management ProtocolSNMP 3

Security Protocols & FeaturesIPsec, SSL

RAM

Installed Size1 GB

Max Supported Size3 GB

ENVIRONMENTAL STANDARDS

ENERGY STARYes

CARD READER

Typecard reader

Supported Flash Memory CardsSD Memory Card, SDHC Memory Card

PRINTING

Max Resolution B/W1200 x 1200 dpi

Max Resolution Color1200 x 1200 dpi

Max Printing Speed B/W (ppm)32 ppm

Max Printing Speed Color (ppm)32 ppm

Automatic DuplexingYes

MEDIA HANDLING

Min Media Size (Custom)2.76 in x 5.83 in

Max Media Size (Custom)8.5 in x 14 in

Media Weight60 g/m² - 220 g/m²

Max Media Capacity2100 sheets

Output Trays Capacity250 sheets

Media TypePlain paper

Total Media Capacity600 sheets

Media SizesLetter A Size (8.5 in x 11 in), Legal (8.5 in x 14 in), A4 (8.25 in x 11.7 in), A5 (5.83 in x 8.25 in), B5 (6.93 in x 9.83 in), A6 (4.13 in x 5.83 in), Folio (8.5 in x 13 in), B6 (4.92 in x 6.93 in)

SYSTEM REQUIREMENTS

OS RequiredApple MacOS X 10.5 or later, Microsoft Windows 7 / 8 / 8.1 / 10, Microsoft Windows Server 2008, Microsoft Windows Server 2012, Microsoft Windows Server 2016

DUTY CYCLE

Monthly Duty Cycle (max)100000 pages

ENVIRONMENTAL PARAMETERS

Sound Emission (Idle)30 dBA

Sound Emission (Operating)49.5 dBA

DOCUMENT & MEDIA HANDLING

Media Type Classplain paper

Media Size ClassA4/Legal

HEADER

BrandKyocera

Product LineKyocera ECOSYS

ModelP6230cdn

Packaged Quantity1

INTERFACE REQUIRED

Connector Type4 pin USB Type A, RJ-45

TypeGigabit LAN, USB 2.0, USB host

Total Qty1, 2

OFFICE MACHINE

Typeprinter

Functionsprinter

Monthly Duty Cycle Range (Printer Class)100,000 pages and more

Monthly Duty Cycle (max)100000 pages

Printing Technologylaser

Printing Output Typecolor



EXPANSION SLOTS

Total Qty1

Typeexpansion slot

CONSUMABLES INCLUDED

Colorblack, cyan, magenta, yellow

Included Qty1

PRINTING SYSTEM

First Print Out Time B/W7 sec

Color Management FeaturesMopria

PRINTER OUTPUT

Max Speed26 ppm, 30 ppm, 32 ppm

Media SizeA4 (8.25 in x 11.7 in), Legal (8.5 in x 14 in), Letter A Size (8.5 in x 11 in)

Output QualityB/W, color

PRINTER MEDIA

Media Load Typeautomatic

Media Feeder Qty1

Media Feeder Max FormatLegal (8.5 in x 14 in)

Min Media Weight60 g/m²

Max Media Weight163 g/m², 220 g/m²

Media Feeder Capacity100 sheets, 500 sheets

PC CONNECTIVITY

InterfaceGigabit LAN, USB 2.0, USB host

AirPrint EnabledYesGENERAL

ManufacturerKyocera
