INTEL CM8071504650608SRL5Y Core i5-12400
Intel CPU Desktop Core i5-12400 (2.5GHz, 18MB, LGA1700) tray
Specification
Item CM8071504650608SRL5Y
Manufacturer INTEL
Product Type CPU - desktop
Processor INTEL Core i5-12400
Internal clock frequency 2.50 GHz
Performance-core Base Clock Rate 2.5 GHz
Turbo Clock Rate 4.40 GHz
Performance-core Turbo Clock Rate 4.4 GHz
Number of cores 6
Performance-cores Quantity 6
Threads Quantity 12
Core name Alder Lake
1700 CPU socket
Offers L2 cache capacity of 7.5 MB
It offers L3 cache capacity of 18 MB
Architecture Execute Disable Bit
Hyper-Threading Technology
Intel Enhanced SpeedStep Technology
Intel Virtualization Technology
Streaming SIMD Extensions 4.1
Streaming SIMD Extensions 4.2
Thermal Monitoring Technologies
Advanced Vector Extensions 2.0
Intel Turbo Boost Technology 2.0
Intel Virtualization for Directed I/O
Intel Virtualization Technology with Extended Page Tables (EPT)
Intel AES New Instructions
Intel 64
Idle States (C-states)
Intel Secure Key
Intel Device Protection Technology with Boot Guard
Intel Quick Sync Video
Intel Clear Video HD Technology
Intel Optane Memory Supported
Intel OS Guard
Intel Deep Learning Boost
PCI Express 4.0 support
Intel Gaussian & Neural Accelerator 3.0
Intel Speed Shift Technology
Intel Volume Management Device (VMD)
Mode-based Execute Control (MBE)
Intel Control-Flow Enforcement Technology
PCI Express 5.0 Support
Substrate size 7 nm
64 bit instruction set
Power consumption during operation 65 W
Maximum TDP 117 W
DDR4/DDR5 memory types
The maximum memory size is 128GB
Memory channels 2
Supported Memory Speed 3200MHz(PC4-25600)/4800MHz(PC5-38400)
Max Number of PCI Express Lanes 20
Max Number of DMI Lanes 8
Graphics accelerator INTEL UHD Graphics 730
The frequency of the graphics accelerator 300 MHz
Cooling Method No
Warranty
Warranty products - subject to return Yes
Warranty Validity Criteria Serial Number
Logistics information
Package Weight - Gross (kg) 0.1 kg
Package Weight - Net (kg) 0.1 kg
Quantity per pack 1
Carton weight - Gross (kg) 0.1 kg
Packages in Carton 1
Package type Tray
