• Connectable to the third-party network cameras
• Up to 8 network cameras can be connected
• H.264+ compression effectively reduces the storage space and costs by up to 50%
• Full channel recording at up to 4 MP resolution
• HDMI/VGA output at 1080p resolution
• Up to 2-ch synchronous playback at 4 MP resolution or 4-ch at 1080p resolution
• 1 SATA hard disks can be connected with 6TB capacity
• Supports multiple VCA(Video Content Analytics) events detection
• Smart search for the selected area in the video
• and smart playback to improve the playback efficiency
• One-key operation: automatically search, modify and add IP cameras after device is activated
• 100 Mbps Ethernet network interface

Video/Audio input

• IP video input4-ch
• Two-way audio input1-ch, RCA (2.0 Vp-p, 1kΩ)

Network

• Incoming bandwidth40 Mbps
• Outgoing bandwidth40 Mbps
• Remote connection64

Video/Audio output

• Recording resolution4 MP/3 MP/1080p/1.3 MP/UXGA/720p/VGA/4CIF/DCIF/2CIF/ CIF/QCIF
• HDMI/VGA output1-ch, resolution: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
• Audio output1-ch, RCA (Linear, 1kΩ)

Decoding

• Live view/Playback resolution4 MP/3 MP/1080p/1.3 MP/UXGA/720p/VGA/4CIF /DCIF/2CIF/CIF/QCIF
• Capability2-ch@4 MP, 4-ch@1080p

Hard disk

• SATA1 SATA interface for 1 HDD
• CapacityUp to 6TB for each disk

Network management

• Network protocolsTCP/IP, DHCP, Hik-Connect, DDNS, NTP, SADP, SMTP, UPnP™

External interface

• Network interface1 RJ-45 10/100 Mbps self-adaptive Ethernet interface
• USB interface2 × USB 2.0

General

• Power supply12 VDC
• Consumption (without hard disk)≤ 18 W
• Working temperature-10 ºC to +55 ºC (14 ºF to 131 ºF)
• Working humidity10 % to 90 %
• Dimensions (W × D × H)200 × 205 × 48 mm (7.9" × 8.1" × 1.9")
• Weight (without hard disk)≤ 1 kg (2.2 lb)
