Characteristics
• Pair consists of receiver and transmitter is a full functional module and requires no configuration
• Cable Cat5e / 6 replaces the HDMI cable to achieve a longer transmission distance
• Complies with IEEE-568B
• The distance signal transmission can reach 30 meters 1080p using UTP cable with inner liner of pairs
• Compact size
• Supports full 1080p display resolution
• Supports bandwidth up to 165MHz / 1.65Gbps per channel (4.95Gbps all channel)
• Supports 8-bit deep color per channel (24bit all channel)
• HDCP pass-through
• Supports uncompressed audio such LPCM
• Supports compressed audio DTS Digital, Dolby Digital (including DTS-HD and Dolby True HD)
• Supports all 3D formats

Specification
• Video input signal 0.5 -1.0 volts p-p
• Input DDC Signal 5 volts p -p (TTL)
• Maximum Single Link Range 1920x1080p
• HDMI video output
• Transmission distance: With UTP cable with inner liner pairs 30m 1080p
• Resolutions (HDTV) Interlaced (50 & 60Hz) 480i, 576i, 1080i
• Progressive (50 & 60Hz) 480p, 576p, 720p, 1080p
