Item

Specification

Item

Specification

Frequency Range

45~870MHz

Input Level

0.8Vp-p for 80%±10% modulation

Output Level

85dBuV

Input Level Ad j

0.4Vp-p ~ 0.8Vp-p

A/V Ratio

-15±2dB

S/N Ratio

55dB

Visual Carrier Freq. Accuracy

±5KHz

Freq. Response

±2.5dB(50Hz to 4.2MHz)

Output Return Loss

14dB

Input Impedance

75Ω

Spurious Rejection

50dB

Output Impedance

75Ω

AUDIO

GENERAL

Item

Specification

Item

Specification

Freq. Deviation

±50KHz

Input Voltage

AC 230V 50Hz

Freq. Response

±2dB

Operation Temperature

-20℃ to+ 50℃

Input Impedance

600Ω
