Fireclass MR601TEx 516.054.011.Y Conventional intrinsically safe optical smoke detector



Ex Conventional intrinsically safe optical smoke detector with microprocessor control for potentially explosive rooms. LED indicator, parallel signal output. Working voltage DC16~28V, standby current 90~110μA, current in alarm state 30mA. Operating temperature: - 20°~70°C. ABS Body dimensions Ø 109x43mm. Suitable for zones 0 to 20. EN standards: EN 54-7: 2000 + A1: 2002; EN50130-4; EN50 014; EN50 020, EN 60079-0:2006; EN60079-11:2007; EN61241-11:2006; ATEX: Ex II 1G, Cenelec: EEX is IIC T5.



The MR601TEx detectors react to the whole range of fire products from slow smouldering fires, producing visible particles to open flaming fires producing large numbers of very hot smaller sized aerosols. It combines optical and heat detector technology to detect clear burning fire products which hitherto could only be easily detected by ion-chamber detectors.



For normal ambient conditions, the high-performance optical detector behaves as a normal optical detector. Only when a rapid rise in temperature is detected does the sensitivity of the detector increase and the presence of smoke will confirm a fire condition which will be transmitted as an alarm level.



The MR601TEX overcomes the slower response of optical detectors to hot burning fires by increasing the sensitivity of the optical detector when it is associated with a rapid change in temperature. In this way it is intended to become a detector which will suit some of the risks currently covered by ion chamber detectors. Smoke detectors will not detect burning alcohol or other clean burning liquids which do not generate smoke particles.



The MR601TEx detector is designed to comply with EN 50 014 and EN 50 020 for intrinsically safe apparatus and is certified: to ATEX Code: Ex II 1G and Cenelec Code: EEx ia IIC T5.



Key Features



Intelligent Universal Smoke/Heat/CO detector

Low profile, discreet and unobtrusive

Superior performance and reliability

Designed for fast, easy installation

Optional locking kit

May be used in systems that meet BS5839 Pt 1

Integral and remote alarm LED

Certified to ATEX: Ex II 1GD and Cenelec: Ex ia IIC T5/Ex iaD 20 T100oC

Complies to EN54-7 for Smoke Detectors and EN54-5 for Heat Detectors
