EMP Centauri DiSEqC switch S4/1PCT-W2 (P.169-TW)

19.90 €
Συμπεριλαμβάνεται Φ.Π.Α. 20%
χωρίς τα έξοδα αποστολής

Κωδικός: 14109

Βάρος: 0.300 kg
Μη Διαθέσιμο

Τεχνικά Στοιχεία Βασικά Στοιχεία Αξιολόγηση

Product description:

4in/1out universal DiSEqC switch designed for use in various reception strategies and for 1 subscriber. One of the satellite inputs transmits terrestrial signals.
Although it can be used as standard DiSEqC 1.0 switch, it's unique features predeterminate it for use as "Uncommitted" DiSEqC 1.1 switch or as DiSEqC 1.2 to DiSEqC 1.0 transcoder, allowing to extent multiswitch system for up to 16 quatro/quad LNBs. Please read carefully Instruction Manual before purchase and setting up.

Brief specification:

Parameter	Condition	Value
Frequency range	LNB inputs 1, 3, 4	950-2300 MHz
	LNB+Terr. input 2	5-862, 950-2300 MHz
	Output	5-2300 MHz
Control		DiSEqC 1.0, 1.1, 1.2 commands
Insertion loss	Sat.	5 dB avg
Insertion loss	Terr.	5 dB avg
Sat. inputs isolation		25 dB min
Power consumption	From receiver	35 mA (18V) + LNB
Power consumption	DC current pass	400 mA max
Dimensions (w,d,h)		11.2 x 11.2 x 4.9 cm
Temperature range		-30 ~ +70°C

Τιμή Μονάδος: 19.90 €
Κατασκευαστής: EMP Centauri
Βάρος: 0.300 kg
