DELL EMC PER240CEEM02-CFG02-14 Server,Xeon E-2244G 3.8GHz 8M 4C/8T



PER240 Server,Xeon E-2244G 3.8GHz 8M 4C/8T,3.5" Chassis x4 Cabled HDD,PCIe Riser 1xFH x8 Gen3,1x LPx4 Gen3,16GB UDIMM 3200MT/s ECC,iDRAC9 Basic,1TB SATA HDD,PERC H330,450W PSU,TPM 2.0,LOM DP 1Gbe,Rails,3Y NBD



The system

Server system type

Rack-Mountable system form factor

Rails accessories included

Processor

Intel Xeon Processor E-2244G Processor

Internal clock frequency 3.8 GHz (up to 4.8 GHz)

Number of CPU cores 4

Threads Quantity 8

Maximum CPU bus clock speed 8 GT / sec

Socket 1151 processor socket

Number of processors installed 1

Max. number of installed processors 1

CPU Cache Size 8 MB

Characteristics Supports 14 nm Processors

Number of supported motherboards 1



Memory

DDR4 SDRAM memory type

Memory factor form DIMM 288-pin

Memory speed / frequency 3200MHz (PC4-25600)

Proposes an ECC error checking method

Amount of installed system memory 16 GB

Maximum amount of installed memory 64 GB

Total number of memory slots 4

Memory characteristics Unbuffered



Controller

Plug-in-card Remote Management Controller:

iDRAC9 Basic

RAID Controller:

PERC H330

Supports: Level 0, Level 1, Level 10, Level 5, Level 50

SAS / SATA (2 x SFF-8644)



Data storage device

Hard Disk Drive 1 TB, SATA III-600



Video output

Video controller - form factor Built-in



Network specifications

Network device form factor Built-in

Gigabit Ethernet LAN

Supported Gigabit Ethernet / Fast Ethernet / Ethernet data exchange protocols



Nests provided

Number of internal slots for 3.5-inch devices 4



Slots provided

PCI Express 3.0 x8 1

PCI Express 3.0 x16 1



Supported interfaces

USB 3.0 2 (USB 3.0 (type A))

USB 2.0 1 (USB 2.0 (type A))

LAN 2 (RJ-45)

Serial 1 (9-pin)

VGA 1 (15-pin D-sub)



Power

Power type Power supply module

Power supply location Internal

Input voltage AC 100-240 V

Input frequency 50/60 Hz

Number of installed power supplies 1;

Max. number of supported power supplies 1

Maximum output power 450 W



Other features

Exterior color Black

Types of Rackmount mounting

Standard cabinet height 1 U

Rails accessories included



Dimensions and weight

Height 42.8 mm

Depth 595.6 mm

Width 434 mm



Warranty

Warranty products - refundable Yes

Warranty validity criteria Serial number

Warranty Deadline Next Business Day



Logistic information

Package weight - Gross (kg) 10 kg

Package weight - Net (kg) 0 kg
