Technical specifications

Number of inputs 4

Number of outputs 1

Test output yes : -30 dB

Gain inputBI+FM (dB) 28

Gain input BIII (DAB) (dB) 40

Gain input UHF1 (dB) 40

Gain input UHF2 (dB) 40

Attenuation range (each input) (dB) 0-18

Noise fi gure(dB) < 7

Input/ouput return loss (dB) > 10

Max. output level (IM3 : -52 dB : 3 equal carriers) (dBμV) 118

Remote power (activated by internal jumper) 5V / 200 mA

Voltage 230 Vac (-10%,+15%)

Power consumption (W) 6

Dimensions (mm)/weight (kg) 170 x 95 x 50 / 0.8

Code EAN 5420037601165
