Specifications
Number of inputs    3
Number of outputs    1
Test output    Oui : -30dB
Gain UHF (21-48 or 21-60)    40
Gain BIII (DAB)    33
Gain FM    24
Attenuation range (each input) (dB)    0-18
Noise figure (dB)    < 7
Input output return loss (dB)    > 10
Output level (DIN45004B) (dBuV)    120
Supply voltage    230 Vac (-10%, +15%)
Consumption (W)    6
Dimensions (mm) weight (kg)    193 x 124 x 44 / 0.85
