Ajax Motion Protect Outdoor Wireless PIR detector for movement 12895.33.WH1



Wireless outdoor motion detector with a photo camera to verify alarms



Lightning-fast alarms. Verified.



MotionCam Outdoor recognizes intrusion from the very first steps on the territory and confirms it with an animated series of photos. Visual verification helps to instantly ascertain the situation, saving users from concerns, and security companies from unnecessary patrol dispatches.



Don't miss a thing



Combining the best optics, fast processor and advanced software algorithms, MotionCam Outdoor takes informative pictures in any weather, day or night.



Intelligent false alarm filter



MotionCam Outdoor is equipped with two independent PIR sensors, the signals of which are analyzed by a two-step LISA algorithm. When both sensors detect motion, LISA performs correlation and spectral analysis of the signals, which helps to instantly distinguish real threats from interferences.



Correlation analysis



Whenever MotionСamOutdoor detects motion, LISA analyses and compares signal forms from two sensors in real-time. If forms are similar, the alarm is activated.



Multilevel anti-sabotage protection



MotionCam Outdoor can not be unnoticeably disabled even if the system is disarmed. The detector is equipped with masking sensors reacting to hindering, covering and painting the lens.



It will take the hub less than a minute1 to detect the loss of communication with the detector and inform a central monitoring station and users about the problem. The fact that MotionCam Outdoor was dismantled will become known instantly.



Effective security in any weather



MotionCam Outdoor resists the heat up to +60°С and withstand the cold down to −25°С. And to protect the sensors of the anti-masking system from rain and snow, we included a special hood.



Efficiency in heat and cold



IP55 enclosure protection



Bundled hood to protect from rain and snow



Uncompromising communication reliability



MotionCam Outdoor uses two secure radio protocols simultaneously: Jeweller and Wings. Radio protocols work independently of each other and each is focused on its own function. Jeweller transmits alarms in 0.15 seconds, and thanks to Wings, the first shot from the site will be in the app in less than 9 seconds2.



Wireless PIR detector for movement and immunity to pets up to 80 cm, and anti-masking. Communication from the panel up to 1700 m. IP55. Range from 3 to 15 m / 90 °. Mounting height - 0.8 - 1.3 m. Stand and battery included in the set (2xCR123A). For indoor or outdoor installation.



Dimensions 206 × 108 × 93 mm



Weight 470 g
