Night Vision - Automatic night vision functionality supports 24-hour surveillance
Advanced H.264 Video - For amazingly smooth HD video streaming
tpCamera App - Use the tpCamera app to access feeds from anywhere, at any time
Motion & Sound Detection - Immediate notification by email whenever motion or sound is detected
Easy Setup - Install and operate the camera within minutes
300Mbps Wireless - 300Mbps wireless for fluid video and Wi-Fi extension
| CAMERA | |
|---|---|
| Image Sensor | 1/4" Progressive scan CMOS sensor |
| Resolution | 0.3 Megapixel (640 x 480) |
| Lens | F: 2.8, f: 3.85 mm |
| Viewing Angle | FOV = 64° |
| Digital Zoom | 4x Digital |
| VIDEO/IMAGE | |
|---|---|
| Video Compression | H.264 |
| Frame Rate & Resolutions |
Max. 30 fps at 640x480 (VGA) Max. 30 fps at 320x240 (QVGA) |
| Video Streaming | Controllable Frame rate |
| Image Settings |
Rotation: Mirror, Flip Configurable brightness, contrast, saturation Overlay capabilities: time, date, text |
| AUDIO | |
|---|---|
| Audio Communication | 1-Way |
| Audio Input | Built-in microphone |
| ALARM AND EVENT MANAGEMENT | |
|---|---|
| Notification | |
| Triggering Event | Motion/Sound detection |
| NETWORK | |
|---|---|
| Standards and Protocols |
Bonjour, TCP/IP, DHCP, PPPoE, ARP, ICMP, FTP, SMTP,DNS, UPnP, HTTP and UDP |
| Security | Multiple password-protected user levels |
| WIRELESS | |
|---|---|
| Wireless Data Rates | IEEE 802.11 b/g/n, Up to 300Mbps |
| Frequency | 2.4-2.4835GHz |
| Wireless Transmit Power | <20dBm (EIRP) |
| Wireless Encryption | WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| INTERFACES | |
|---|---|
| Network Interface | RJ-45 for Ethernet 10/100 Base-T |
| Power Connector | DC power jack |
| Button | Reset/WPS push button |
| SURVEILLANCE MANAGEMENT | |
|---|---|
| Free Management Software | Viewing and recording up to 36 cameras |
| MINIMUM SYSTEM REQUIREMENTS | |
|---|---|
| Supported OS |
Windows 10/8/7/Vista/XP OS X or higher iOS 7.0 or higher Android 3.0 or higher |
| Supported Browser | Mozilla Firefox 4.0, Opera 12, Safari 4.0, IE 7.0 or higher |
| GENERAL | |
|---|---|
| External Power Supply | 9V DC, Max 5.4W |
| Certification | RoHS, FCC, CE |
| Package Contents |
NC220 Power Adapter Extension Cable RJ-45 Ethernet Cable Quick Installation Guide |
| Environment |
Operating Temperature: 0°C~40°C (32°F ~104°F) Storage Temperature: -40°C ~70°C (-40°F ~158°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
| Dimensions( H X W X D ) | 5.4 x 3.0 x 2.7 in. ( 137 x 76 x 69 mm ) |
| Packaging Dimensions | 5.0 x 3.1 x 8.8 in. (128 x 79.5 x 223mm) |
